Drone 3D Modeling
7 Week time frame

Guia is a companion hiking drone, a friendly guide that shows the best direction. Composed by the main base and three speckle drones, the system takes care of the user so that they can focus on the real experience.

about

2600

Injuries are

reported per year

Design Criteria


Friendly

Have an approachable character both in looks and usability

Guide

Know at all times what are the safest directions and interest points


Illuminate

Have the ability to light up the path in case of a night hike

SolidWorks Process


Speckles

Light nodes that swiftly move through the air, showing the correct direction while pinpointing important points and even possible harms.


Aluminum Feet

Polypropylene top armature

ABS Shell

Brushless Motors

Lithium Ion Battery

ABS Handle

Polypropylene tubing

Polycarbonate side-light cover

ABS bottom Shell

Polypropylene bottom armature
